The SJIII 3215 offers Skyjack's easy to service, low maintenance design in a compact and versatile package. Equipped with variable speed front wheel hydraulic drive, and 90 degree steering, the SJIII 3215 is capable of maneuvering in the smallest spaces. Featuring a 3 ft roll out extension deck, a working height of 21 ft and 25% gradeability. Technical Specification : Ground Clearance (Stowed) 2.375" (6.0 cm) Lift Time (With Rated Load) 23 sec Extension Deck (Roll Out) 3 ft (0.9 m) Work Height 21 ft (6.4 m) Wheelbase 55" (1.4 m) Raised Platform Height 15 ft (4.6 m) Turning Radius - Outside 66" (1.7 m) Maximum Drive Height Full Height Overall Length 70" (1.8 m) Stowed Height OPT 60.1" (1.5 m) [Rails Down] 74" (1.9 m) [Rails Up] Weight 2,400 lbs (1,089 kg) Ground Clearance 0.7" (1.8 cm) [Raised] Turning Radius (Inside) 0" Drive Speed (Raised) 0.7 mph (1.1 km/h) Maximum # of Persons 2 Overall Width 32" (0.8 m) Drive Speed (Stowed) 2 mph (3.2 km/h) Capacity (Overall) 600 lbs (272 kg)
