Features: • IP 40, ABS Enclosure • Microcontroller based • Compact & Programmable Control • Tactile Switch Input & LED Indication output. Application: • Power Management System • Machine Automation • Genset / Solar Control Unit • Ligthing Control Unit • Process Control Unit such as Heater/ Cooler Specification: Model: PCU 500 Input Volts AC/DC : 0 ~ 50 V - 3 Nos. Tactile switch: Switch - 2 Nos. Output: 2 Nos. Transistor Output LED Indication:3 Nos. Operating Voltage : 9 ~ 36 V DC Working temperature: Up to 45°C Self consumption : 0.5W Overall dimension: 80 x 120 x 55 mm Net weight: 300 G
